Description:

General Specifications

Tunnel Size: 800 (W) X650 (H) mm

Conveyor Speed: 0.22m/s

Conveyor Max Load: 200 kg

Single inspection dosage: < 1.5 uGy

Wire Resolution: 0.101 mm metal line

Steel Penetration : 38MM

Film Safety: For ISO 1600

X-RAY GENERATOR

Orientation: Downward

Tube Current: 0.4~0.7MA (adjustable)

Anode Voltage: 100~ 16010″ ( adjustable)

Angle: 60°

Generator cooling/working periods

Sealed oil bath with forced airs/100%

OPERATING ENVIRONMENT

Storage Temperature: -20C to 60C

Operating Temperature: 0C to 45C

Relative Humidity.

20 to 95% non-condensing

System Power: 220 VAC (+-10%) 50+-3HZ

Power wastage: 1.0 KW (Max)

Noise<65DB

X-RAY Sensor.

L-shaped array detector 24bit

Multy-energy: High/low energy: Switch from high energy to low energy

Color material identification: Organic objects in orange, inorganic objects in blue,

Mixture in green

Assist to detect drug and explosive powder
